When synchronizing with analogue tape decks that exhibit fluctuations in transport speed, RADAR can
reference to the incoming SMPTE signal. In this configuration RADAR will fluctuate right along with the
analogue master ensuring perfect synchronization at all times.
To slave RADAR to external wordclock:
Ensure that a wordclock source is connected to the WORDCLOCK/VIDEO IN connector.
Verify that the project sample rate in the MAIN MENU / PROJECT MENU / SAMPLE RATE
dialogue matches the incoming wordclock frequency.
Press the key on the Session Controller or KC-24 or use the key, the and
keys and the key to go to the MAIN MENU / SYNC MENU / SYNC REFERENCE
menu and press the key.
Use the and keys to select SYNC REFERENCE: WORDCLCK: XX KHZ and press the
key.
If wordclock will be passing through the RADAR make sure that the function of the OUT/THRU
connector is set to THRU in the MAIN MENU / SYNC MENU / SYNC REF OUTPUT dialogue.
The wordclock frequency value displayed in the SYNC REFERENCE dialogue will depend
on the SAMPLE RATE of the current project not the rate of the incoming wordclock signal.
To slave RADAR to external video sync:
Ensure that a video sync source is connected to the WORDCLOCK/VIDEO IN connector. Make
sure that the project’s timecode rate in the MAIN MENU / SYNC MENU / TC SETTINGS /
TC RATE menu matches the incoming video sync frequency.
Press the key on the Session Controller or KC-24 or use the key, the and
keys and the key to go to the MAIN MENU / SYNC MENU / SYNC REFERENCE
menu and press the key.
Use the and keys to select SYNC REFERENCE: VIDEO: NTSC or PAL and press the
key.
The video sync frequency value displayed in the SYNC REFERENCE dialogue will depend
on the TC RATE setting of the SYNC MENU not the rate of the incoming video sync
signal.
