CONFIGURATION
RADAR 3.
5
0
20
To slave RADAR to SMPTE timecode or MTC:
Ensure that a valid SMPTE timecode source is connected to the LTC: SMPTE / EBU connector
using a balanced or unbalanced XLR terminated cable. Connect an MTC source to the MIDI IN
using a MIDI cable.
Use the key, the and keys and the key to go to the MAIN MENU / SYNC
MENU / TC SETTINGS / TC RATE menu and make sure that the timecode rate matches the
incoming timecode signal.
Press the key on the Session Controller or KC-24 or go to MAIN MENU / SYNC MENU
/ SYNC REFERENCE and press the key.
Use the and keys to select SYNC REFERENCE: SMPTE 30 or SYNC REFERENCE: MTC
30 and press the key.
The timecode frequency value displayed in the SYNC REFERENCE dialogue will depend
on the TC RATE setting of the SYNC MENU not the rate of the incoming timecode signal.
MIDI Timecode is a high distortion, slow lock speed format and is not recommended as a
sync reference.
To slave RADAR to an external AES/EBU clock source:
Connect an AES/EBU source to the AES/EBU IN connector using an XLR terminated digital
audio cable.
Press the key on the Session Controller or KC-24 or use the , the and
keys and key to go to the MAIN MENU / SYNC MENU / SYNC REFERENCE menu and
press the key.
Use the and keys to select SYNC REFERENCE: AES 2CH SYNC and press the
key.
To slave RADAR to an external S/PDIF clock source:
Connect the S/PDIF source to the S/PDIF IN connector using an RCA terminated digital audio
cable.
Press the key on the Session Controller or KC-24 or use the , the and
keys and key to go to the MAIN MENU / SYNC MENU / SYNC REFERENCE menu and
press the key.
Use the and keys to select SYNC REFERENCE: S/PDIF 2CH SYNC and press the
key.
