iZ Technology Corporation
Once the PC has been equipped with an FTP Client and an FTP Server, connect an Ethernet crossover
cable between RADAR and the PC. Crossover cables are available at most computer stores. A crossover
Ethernet cable is different from a standard (straight through) Ethernet cable, as the crossover cable has
different wiring. Crossover cables are usually yellow in colour. If the RADAR and PC are connected
through a router, standard Ethernet cables may be used. RADAR can also be integrated into a network
environment; contact the network administrator for specific settings.
PC IP Address and Firewall setup for Windows Vista:
Click the START menu and click CONTROL PANEL.
Click on WINDOWS FIREWALL then click the GENERAL TAB shut off the Firewall and click the
OK button.
In the CONTROL PANEL click on NETWORK AND INTERNET, then NETWORK AND
SHARING CENTER and click to select MANAGE NETWORK CONNECTIONS from the list of
tasks.
Right click on LOCAL AREA CONNECTION and choose PROPERTIES.
Select USE THE FOLLOWING IP ADDRESS and enter a unique IP Address (i.e. 192.168.12)
For SUBNET MASK enter: 255.255.255.0.
Leave all other fields blank.
Click the OK button.
PC IP Address and Firewall setup for Windows XP:
Click the START menu and click CONTROL PANEL.
Click on WINDOWS FIREWALL then click the GENERAL TAB shut off the Firewall and click the
OK button.
Click on NETWORK CONNECTIONS in CONTROL PANEL.
Right click on LOCAL AREA CONNECTION and choose PROPERTIES.
Click on INTERNET PROTOCOL (TCP/IP) and then click PROPERTIES.
Click USE THE FOLLOWING IP ADDRESS and enter a unique IP Address (i.e. 192.168.1.2).
For SUBNET MASK enter: 255.255.255.0
Leave all other fields blank.
Click the OK button.
