228 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
12 :DISPlay Commands
Introduction to
:DISPlay
Commands
The DISPlay subsystem is used to control the display storage and retrieval of
waveform data, labels, and text. This subsystem allows the following actions:
• Clear the waveform area on the display.
• Turn vectors on or off.
• Set waveform persistence.
• Specify labels.
• Save and Recall display data.
Reporting the Setup
Use :DISPlay? to query the setup information for the DISPlay subsystem.
Return Format
The following is a sample response from the :DISPlay? query. In this case, the
query was issued following a *RST command.
:DISP:LAB 0;VECT 1;PERS MIN
:DISPlay:LABList
<binary block> (see
page 237)
:DISPlay:LABList?
(see page 237)
<binary block> ::= an ordered
list of up to 75 labels, each 10
characters maximum, separated by
newline characters
:DISPlay:MENU:TIMeout
{<value> | {OFF |
MAX}} (see page 238)
:DISPlay:MENU:TIMeout
? (see page 238)
<value> ::= an integer from 5 to
60 in NR1 format.
:DISPlay:PERSistence
<value> (see page 239)
:DISPlay:PERSistence?
(see page 239)
<value> ::= {MINimum | INFinite |
<time>}
<time> ::= seconds in in NR3
format from 100E-3 to 60E0
:DISPlay:VECTors {1 |
ON} (see page 240)
:DISPlay:VECTors?
(see page 240)
1
Table 57 :DISPlay Commands Summary (continued)
Command Query Options and Query Returns
