:SBUS<n> Commands 24

Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 491

:SBUS<n>:IIC:TRIGger[:TYPE]

(see page 798)

Command Syntax

:SBUS<n>:IIC:TRIGger[:TYPE] <value>

<value> ::= {STARt | STOP | READ7 | READEprom | WRITe7 | WRITe10

| NACKnowledge | ANACk | R7Data2 | W7Data2 | RESTart}

The :SBUS<n>:IIC:TRIGger[:TYPE] command sets the IIC trigger type:

• STARt — Start condition.

• STOP — Stop condition.

• READ7 — 7-bit address frame containing (Start:Address7:Read:Ack:Data). The

value READ is also accepted for READ7.

• R7Data2 — 7-bit address frame containing

(Start:Address7:Read:Ack:Data:Ack:Data2).

• READEprom — EEPROM data read.

• WRITe7 — 7-bit address frame containing (Start:Address7:Write:Ack:Data). The

value WRITe is also accepted for WRITe7.

• W7Data2 — 7-bit address frame containing

(Start:Address7:Write:Ack:Data:Ack:Data2).

• WRITe10 — 10-bit address frame containing (Start:Address

byte1:Write:Ack:Address byte 2:Data).

• NACKnowledge — Missing acknowledge.

• ANACk — Address with no acknowledge.

• RESTart — Another start condition occurs before a stop condition.

Query Syntax

:SBUS<n>:IIC:TRIGger[:TYPE]?

The :SBUS<n>:IIC:TRIGger[:TYPE]? query returns the current IIC trigger type value.

Return Format

<value> ::= {STAR | STOP | READ7 | READE | WRIT7 | WRIT10 | NACK | ANAC

| R7D2 | W7D2 | REST}

See Also • "Introduction to :TRIGger Commands" on page 585

• ":TRIGger:MODE" on page 594

• ":SBUS<n>:IIC:TRIGger:PATTern:ADDRess" on page 487

• ":SBUS<n>:IIC:TRIGger:PATTern:DATA" on page 488

NOTE

The short form of READ7 (READ7), READEprom (READE), WRITe7 (WRIT7), and WRITe10

(WRIT10) do not follow the defined Long Form to Short Form Truncation Rules (see

page 800).
