Keysight InfiniiVision DSOX1204A/G Oscilloscopes
Programmer's Guide
21 :MTESt Commands
Mask testing is available on the DSOX1000-Series oscilloscope models.
The MTESt subsystem commands and queries control the mask test features. See
"Introduction to :MTESt Commands" on page 401.
Table 66 :MTESt Commands Summary
Command Query Options and Query Returns
:MTESt:ALL {{0 | OFF}
| {1 | ON}} (see
page 404)
:MTESt:ALL? (see
page 404)
{0 | 1}
:MTESt:AMASk:CREate
(see page 405)
n/a n/a
:MTESt:AMASk:SOURce
<source> (see
page 406)
:MTESt:AMASk:SOURce?
(see page 406)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:MTESt:AMASk:UNITs
<units> (see page 407)
:MTESt:AMASk:UNITs?
(see page 407)
<units> ::= {CURRent | DIVisions}
:MTESt:AMASk:XDELta
<value> (see page 408)
:MTESt:AMASk:XDELta?
(see page 408)
<value> ::= X delta value in NR3
format
:MTESt:AMASk:YDELta
<value> (see page 409)
:MTESt:AMASk:YDELta?
(see page 409)
<value> ::= Y delta value in NR3
format
n/a :MTESt:COUNt:FWAVefor
ms? [CHANnel<n>] (see
page 410)
<failed> ::= number of failed
waveforms in NR1 format
:MTESt:COUNt:RESet
(see page 411)
n/a n/a
n/a :MTESt:COUNt:TIME?
(see page 412)
<time> ::= elapsed seconds in NR3
format
n/a :MTESt:COUNt:WAVeform
s? (see page 413)
<count> ::= number of waveforms
in NR1 format
