:EXTernal Trigger Commands 14
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 253
:EXTernal:LABel
(see page 798)
Command Syntax
:EXTernal:LABel <string>
<string> ::= quoted ASCII string.
The :EXTernal:LABel command sets the external trigger input's label.
Setting a label for the external waveform also adds the name to the label list in
non-volatile memory (replacing the oldest label in the list).
Query Syntax
:EXTernal:LABel?
The :EXTernal:LABel? query returns the label associated with the external trigger
input.
Return Format
<string><NL>
<string> ::= quoted ASCII string.
See Also • ":EXTernal:DISPlay" on page 252
• ":DISPlay:LABel" on page 236
Label strings are 10 characters or less, and may contain any commonly used ASCII characters.
Labels with more than 10 characters are truncated to 10 characters. Lower case characters
are converted to upper case.
