Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 3
In This Book
This book is your guide to programming the InfiniiVision DSOX1204A/G
oscilloscopes:
The first few chapters describe how to set up and get started:
• Chapter 1, “What's New,” starting on page 25, describes programming
command changes in the latest version of oscilloscope software.
• Chapter 2, “Setting Up,” starting on page 31, describes the steps you must take
before you can program the oscilloscope.
• Chapter 3, “Getting Started,” starting on page 37, gives a general overview of
oscilloscope program structure and shows how to program the oscilloscope
using a few simple examples.
• Chapter 4, “Commands Quick Reference,” starting on page 49, is a brief listing
of the DSOX1204A/G oscilloscope commands and syntax.
The next chapters provide reference information on common commands, root level
commands, other subsystem commands, and error messages:
• Chapter 5, “Common (*) Commands,” starting on page 107, describes
commands defined by the IEEE 488.2 standard that are common to all
instruments.
• Chapter 6, “Root (:) Commands,” starting on page 133, describes commands
that reside at the root level of the command tree and control many of the basic
functions of the oscilloscope.
• Chapter 7, “:ABUS Commands,” starting on page 167, describes commands
that control all oscilloscope functions associated with the analog channels bus
display.
Table 1 DSOX1204A/G Model Numbers, Bandwidths
Model: DSOX1204A DSOX1204G
Channels: 4
Bandwidth: 70 MHz
Bandwidth upgrades: 70 MHz to 100 MHz with D1200BW1A upgrade
70 MHz to 200 MHz with D1200BW2A upgrade
100 MHz to 200 MHz with D1200BW3A upgrade
Sampling rate: 2 GSa/s (interleaved), 1 GSa/s (non-interleaved)
Memory: 1 Mpts
Segmented memory: Yes
Waveform generator: No Yes (20 MHz)
Mask/limit test: Yes
