336 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide

19 :MARKer Commands

:MARKer:Y1Position

(see page 798)

Command Syntax

:MARKer:Y1Position <position> [suffix]

<position> ::= Y1 cursor position in NR3 format

<suffix> ::= {mV | V | dB}

If the :MARKer:MODE is not currently set to WAVeform (see ":MARKer:MODE" on

page 328), the :MARKer:Y1Position command:

• Sets :MARKer:MODE to MANual.

• Sets the Y1 cursor position to the specified value.

Y cursor units are set by the :MARKer:YUNits command.

When the :MARKer:MODE is set to WAVeform, Y positions cannot be set.

Query Syntax

:MARKer:Y1Position?

The :MARKer:Y1Position? query returns current Y1 cursor position. This is

functionally equivalent to the obsolete :MEASure:VSTArt command/query.

Return Format

<position> ::= Y1 cursor position in NR3 format

See Also • "Introduction to :MARKer Commands" on page 326

• ":MARKer:MODE" on page 328

• ":MARKer:X1Y1source" on page 330

• ":MARKer:X2Y2source" on page 332

• ":MARKer:Y2Position" on page 337

• ":MARKer:YUNits" on page 339

• ":MEASure:VSTArt" on page 742

NOTE

If the front-panel cursors are off or are set to Binary or Hex Mode, the marker position values

are not defined and an error is generated. Make sure to set :MARKer:MODE to MANual or

WAVeform to put the cursors in the front-panel Normal mode.
