Keysight Technologies InfiniiVision DSOX1204A User Manual

28 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
1 What's New
Command Differences From 1000 X-Series Oscilloscopes
The Keysight InfiniiVision DSOX1204A/G oscilloscopes command set is most
closely related to the InfiniiVision 1000 X-Series oscilloscopes (and the
2000/3000 X-Series, 7000 Series, 6000 Series, and 54620/54640 Series
oscilloscopes before them).
The main differences between the version 2.00 programming command set for the
InfiniiVision DSOX1204A/G oscilloscopes and the 1.10 programming command set
for the InfiniiVision 1000 X-Series oscilloscopes are related to:
• The DSOX1204A/G oscilloscopes have 4 analog input channels, the previous
1000 X-Series oscilloscopes have 2 analog input channels and an Ext Trig input
that can be used like a single digital input channel.
• The Ext Trig input cannot be included in a bus made up of analog channels.
• The Ext Trig input cannot be included in a pattern trigger.
• The Ext Trig input cannot be a source for serial bus decodes.
• The DSOX1204A/G oscilloscopes have a LAN interface in addition to the USB
device interface.
• Four count measurements are added to the DSOX1204A/G oscilloscopes:
positive pulse count, negative pulse count, rising edge count, and falling edge
count.
More detailed descriptions of the new, changed, obsolete, and discontinued
commands appear below.
New Commands
Command Description
:HARDcopy:NETWork:ADDRess
(see page 319)
Sets the address for a network printer slot.
:HARDcopy:NETWork:APPLy
(see page 320)
Applies the network printer settings and makes the printer
connection.
:HARDcopy:NETWork:SLOT
(see page 321)
Selects the network printer slot used for the address and apply
commands.
:MEASure:NEDGes (see
page 365)
Counts the number of falling edges.
:MEASure:NPULses (see
page 366)
Counts the number of negative pulses.
:MEASure:PEDGes (see
page 370)
Counts the number of rising edges.
:MEASure:PPULses (see
page 373)
Counts the number of positive pulses.
:SYSTem:DIDentifier? (see
page 549)
Returns the oscilloscope's Host ID string.
