:SBUS<n> Commands 24
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 503
:SBUS<n>:LIN:TRIGger:PATTern:DATA
(see page 798)
Command Syntax
:SBUS<n>:LIN:TRIGger:PATTern:DATA <string>
<string> ::= "n" where n ::= 32-bit integer in unsigned decimal when
<base> = DECimal
<string> ::= "nn...n" where n ::= {0 |1|X|$}when
<base> = BINary
<string> ::= "0xnn...n" where n ::= {0,..,9 | A,..,F |X|$}when
<base> = HEX
The :SBUS<n>:LIN:TRIGger:PATTern:DATA command specifies the LIN trigger data
pattern searched for in each LIN data field.
Set a <string> bit to "0" or "1" to set the corresponding bit in the data pattern to
low or high, respectively.
Set a <string> bit to "X" to ignore (mask off) that bit in the data pattern.
Use the "$" character to indicate that the value of the corresponding bit will not be
changed (the existing bit value is used).
When <base> = DECimal, the "X" and "$" characters cannot be entered. When
queried, the "$" character is returned when any bits in the pattern have the value
of "X" and <base> = DECimal. When any bits in a given nibble have the value of "X"
and <base> = HEX, the "$" character is returned for the corresponding nibble.
Query Syntax
:SBUS<n>:LIN:TRIGger:PATTern:DATA?
The :SBUS<n>:LIN:TRIGger:PATTern:DATA? query returns the currently specified
LIN trigger data pattern.
Return Format
<string><NL>
<base> is specified with the :SBUS<n>:LIN:TRIGger:PATTern:FORMat command. The default
<base> is BINary.
The length of the trigger data value is determined by the
:SBUS<n>:LIN:TRIGger:PATTern:DATA:LENGth command.
If more bits are sent for <string> than the specified trigger pattern data length, the most
significant bits will be truncated. If the data length size is changed after the <string> is
programmed, the added or deleted bits will be added to or deleted from the least significant
bits.
