Keysight Technologies InfiniiVision DSOX1204A User Manual

:TRIGger Commands 27
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 611
:TRIGger:PATTern Commands
NOTE
The :TRIGger:PATTern commands are available on the DSOX1000-Series oscilloscopes only.
Table 80 :TRIGger:PATTern Commands Summary
Command Query Options and Query Returns
:TRIGger:PATTern
<string>[,<edge_sourc
e>,<edge>] (see
page 612)
:TRIGger:PATTern?
(see page 612)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | R | F} when <base> =
ASCii
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
<edge_source> ::= {CHANnel<n> |
NONE}
<n> ::= 1 to (# analog channels)
in NR1 format
<edge> ::= {POSitive | NEGative}
:TRIGger:PATTern:FORM
at <base> (see
page 614)
:TRIGger:PATTern:FORM
at? (see page 614)
<base> ::= {ASCii | HEX}
:TRIGger:PATTern:QUAL
ifier <qualifier>
(see page 615)
:TRIGger:PATTern:QUAL
ifier? (see page 615)
<qualifier> ::= ENTered
