290 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
17 :FUNCtion Commands
:FUNCtion:GOFT:SOURce
1 <source> (see
page 300)
:FUNCtion:GOFT:SOURce
1? (see page 300)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:FUNCtion:GOFT:SOURce
2 <source> (see
page 301)
:FUNCtion:GOFT:SOURce
2? (see page 301)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:FUNCtion:OFFSet
<offset> (see
page 302)
:FUNCtion:OFFSet?
(see page 302)
<offset> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
:FUNCtion:OPERation
<operation> (see
page 303)
:FUNCtion:OPERation?
(see page 303)
<operation> ::= {ADD | SUBTract |
MULTiply | DIVide | FFT |
FFTPhase | LOWPass}
:FUNCtion:RANGe
<range> (see page 305)
:FUNCtion:RANGe? (see
page 305)
<range> ::= the full-scale
vertical axis value in NR3
format.
The range for ADD, SUBT, MULT is
8E-6 to 800E+3.
The range for the FFT function is
8 to 800 dBV.
:FUNCtion:REFerence
<level> (see page 306)
:FUNCtion:REFerence?
(see page 306)
<level> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
:FUNCtion:SCALe
<scale
value>[<suffix>] (see
page 307)
:FUNCtion:SCALe? (see
page 307)
<scale value> ::= integer in NR1
format
<suffix> ::= {V | dB}
:FUNCtion:SOURce1
<source> (see
page 308)
:FUNCtion:SOURce1?
(see page 308)
<source> ::= {CHANnel<n> | GOFT}
<n> ::= 1 to (# analog channels)
in NR1 format
GOFT is only for FFT operation.
:FUNCtion:SOURce2
<source> (see
page 309)
:FUNCtion:SOURce2?
(see page 309)
<source> ::= {CHANnel<n> | NONE}
<n> ::= 1 to (# analog channels)
in NR1 format, depending on
SOURce1 selection
Table 62 :FUNCtion Commands Summary (continued)
Command Query Options and Query Returns
