23 :SAVE Commands
Introduction to
:SAVE Commands
The :SAVE subsystem provides commands to save oscilloscope setups, screen
images, and data.
:SAVE:PWD <path_name>
(see page 452)
:SAVE:PWD? (see
page 452)
<path_name> ::= quoted ASCII
string
:SAVE:SETup[:STARt]
[<file_spec>] (see
page 453)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-9; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:SAVE:WAVeform[:STARt
] [<file_name>] (see
page 454)
n/a <file_name> ::= quoted ASCII
string
:SAVE:WAVeform:FORMat
<format> (see
page 455)
:SAVE:WAVeform:FORMat
? (see page 455)
<format> ::= {ASCiixy | CSV |
BINary | NONE}
:SAVE:WAVeform:LENGth
<length> (see
page 456)
:SAVE:WAVeform:LENGth
? (see page 456)
<length> ::= 100 to max. length;
an integer in NR1 format
:SAVE:WAVeform:LENGth
:MAX {{0 | OFF} | {1
| ON}} (see page 457)
:SAVE:WAVeform:LENGth
:MAX? (see page 457)
{0 | 1}
:SAVE:WAVeform:SEGMen
ted <option> (see
page 458)
:SAVE:WAVeform:SEGMen
ted? (see page 458)
<option> ::= {ALL | CURRent}
:SAVE:WMEMory:SOURce
<source> (see
page 459)
:SAVE:WMEMory:SOURce?
(see page 459)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
NOTE: Only ADD or SUBtract math
operations can be saved as
reference waveforms.
<return_value> ::= <source>
:SAVE:WMEMory[:STARt]
[<file_name>] (see
page 460)
n/a <file_name> ::= quoted ASCII
string
If extension included in file
name, it must be ".h5".
Table 68 :SAVE Commands Summary (continued)
Command Query Options and Query Returns
