60 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:CHANnel<n>:SCALe
<scale>[suffix] (see
page 219)
:CHANnel<n>:SCALe?
(see page 219)
<scale> ::= Vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:UNITs
<units> (see page 220)
:CHANnel<n>:UNITs?
(see page 220)
<units> ::= {VOLT | AMPere}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:VERNier
{{0 | OFF} | {1 |
ON}} (see page 221)
:CHANnel<n>:VERNier?
(see page 221)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
Table 7 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
Table 8 :DEMO Commands Summary
Command Query Options and Query Returns
:DEMO:FUNCtion
<signal> (see
page 224)
:DEMO:FUNCtion? (see
page 225)
<signal> ::= {SINusoid | NOISy |
LFSine | AM | RFBurst | FMBurst |
HARMonics | COUPling | RINGing |
SINGle | CLK | TRANsition | BURSt
| GLITch | UART | CAN | LIN}
:DEMO:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 226)
:DEMO:OUTPut? (see
page 226)
{0 | 1}
Table 9 :DISPlay Commands Summary
Command Query Options and Query Returns
:DISPlay:ANNotation
{{0 | OFF} | {1 |
ON}} (see page 229)
:DISPlay:ANNotation?
(see page 229)
{0 | 1}
:DISPlay:ANNotation:B
ACKground <mode> (see
page 230)
:DISPlay:ANNotation:B
ACKground? (see
page 230)
<mode> ::= {OPAQue | INVerted |
TRANsparent}
:DISPlay:ANNotation:C
OLor <color> (see
page 231)
:DISPlay:ANNotation:C
OLor? (see page 231)
<color> ::= {CH1 | CH2 | CH3 |
CH4 | DIG | MATH | REF | MARKer |
WHITe | RED}
:DISPlay:ANNotation:T
EXT <string> (see
page 232)
:DISPlay:ANNotation:T
EXT? (see page 232)
<string> ::= quoted ASCII string
(up to 254 characters)
