:WAVeform Commands 28
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 635
Introduction to
:WAVeform
Commands
The WAVeform subsystem is used to transfer data to a controller from the
oscilloscope waveform memories. The queries in this subsystem will only operate
when the channel selected by :WAVeform:SOURce is on.
Waveform Data and Preamble
The waveform record is actually contained in two portions: the preamble and
waveform data. The waveform record must be read from the oscilloscope by the
controller using two separate commands, :WAVeform:DATA (see page 642) and
:WAVeform:PREamble (see page 649). The waveform data is the actual data
acquired for each point in the specified source. The preamble contains the
information for interpreting the waveform data, which includes the number of
points acquired, the format of acquired data, and the type of acquired data. The
preamble also contains the X and Y increments, origins, and references for the
acquired data, so that word and byte data can be translated to time and voltage
values.
Data Acquisition Types
:WAVeform:VIEW <view>
(see page 661)
:WAVeform:VIEW? (see
page 661)
<view> ::= {MAIN}
n/a :WAVeform:XINCrement?
(see page 662)
<return_value> ::= x-increment
in the current preamble in NR3
format
n/a :WAVeform:XORigin?
(see page 663)
<return_value> ::= x-origin
value in the current preamble in
NR3 format
n/a :WAVeform:XREFerence?
(see page 664)
<return_value> ::= 0
(x-reference value in the current
preamble in NR1 format)
n/a :WAVeform:YINCrement?
(see page 665)
<return_value> ::= y-increment
value in the current preamble in
NR3 format
n/a :WAVeform:YORigin?
(see page 666)
<return_value> ::= y-origin in
the current preamble in NR3
format
n/a :WAVeform:YREFerence?
(see page 667)
<return_value> ::= y-reference
value in the current preamble in
NR1 format
Table 85 :WAVeform Commands Summary (continued)
Command Query Options and Query Returns
