:WGEN Commands 29
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 671
Introduction to
:WGEN Commands
The :WGEN subsystem provides commands to select the waveform generator
function and parameters.
Reporting the Setup
Use :WGEN? to query setup information for the WGEN subsystem.
Return Format
The following is a sample response from the :WGEN? query. In this case, the query
was issued following the *RST command.
:WGEN:FUNC SIN;OUTP 0;FREQ +1.0000E+03;VOLT +500.0E-03;VOLT:OFFS
+0.0E+00;:WGEN:OUTP:LOAD ONEM
:WGEN:VOLTage:HIGH
<high> (see page 697)
:WGEN:VOLTage:HIGH?
(see page 697)
<high> ::= high-level voltage in
volts, in NR3 format
:WGEN:VOLTage:LOW
<low> (see page 698)
:WGEN:VOLTage:LOW?
(see page 698)
<low> ::= low-level voltage in
volts, in NR3 format
:WGEN:VOLTage:OFFSet
<offset> (see
page 699)
:WGEN:VOLTage:OFFSet?
(see page 699)
<offset> ::= offset in volts in
NR3 format
Table 86 :WGEN Commands Summary (continued)
Command Query Options and Query Returns
