84 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:CAN:TRIGger:
PATTern:ID <string>
(see page 481)
:SBUS<n>:CAN:TRIGger:
PATTern:ID? (see
page 481)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:CAN:TRIGger:
PATTern:ID:MODE
<value> (see page 482)
:SBUS<n>:CAN:TRIGger:
PATTern:ID:MODE? (see
page 482)
<value> ::= {STANdard | EXTended}
Table 22 :SBUS<n>:CAN Commands Summary (continued)
Command Query Options and Query Returns
Table 23 :SBUS<n>:IIC Commands Summary
Command Query Options and Query Returns
:SBUS<n>:IIC:ASIZe
<size> (see page 484)
:SBUS<n>:IIC:ASIZe?
(see page 484)
<size> ::= {BIT7 | BIT8}
:SBUS<n>:IIC[:SOURce]
:CLOCk <source> (see
page 485)
:SBUS<n>:IIC[:SOURce]
:CLOCk? (see page 485)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:IIC[:SOURce]
:DATA <source> (see
page 486)
:SBUS<n>:IIC[:SOURce]
:DATA? (see page 486)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess
<value> (see page 487)
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess? (see
page 487)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATA <value>
(see page 488)
:SBUS<n>:IIC:TRIGger:
PATTern:DATA? (see
page 488)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2 <value>
(see page 489)
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2? (see
page 489)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
QUALifier <value>
(see page 490)
:SBUS<n>:IIC:TRIGger:
QUALifier? (see
page 490)
<value> ::= {EQUal | NOTequal |
LESSthan | GREaterthan}
:SBUS<n>:IIC:TRIGger[
:TYPE] <type> (see
page 491)
:SBUS<n>:IIC:TRIGger[
:TYPE]? (see page 491)
<type> ::= {STARt | STOP | READ7
| READEprom | WRITe7 | WRITe10 |
NACKnowledge | ANACk | R7Data2 |
W7Data2 | RESTart}
