86 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth
<length> (see
page 505)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth?
(see page 505)
<length> ::= integer from 1 to 8
in NR1 format
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat <base>
(see page 506)
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat? (see
page 506)
<base> ::= {BINary | HEX |
DECimal}
Table 24 :SBUS<n>:LIN Commands Summary (continued)
Command Query Options and Query Returns
Table 25 :SBUS<n>:SPI Commands Summary
Command Query Options and Query Returns
:SBUS<n>:SPI:BITorder
<order> (see page 509)
:SBUS<n>:SPI:BITorder
? (see page 509)
<order> ::= {LSBFirst | MSBFirst}
:SBUS<n>:SPI:CLOCk:SL
OPe <slope> (see
page 510)
:SBUS<n>:SPI:CLOCk:SL
OPe? (see page 510)
<slope> ::= {NEGative | POSitive}
:SBUS<n>:SPI:CLOCk:TI
Meout <time_value>
(see page 511)
:SBUS<n>:SPI:CLOCk:TI
Meout? (see page 511)
<time_value> ::= time in seconds
in NR3 format
:SBUS<n>:SPI:FRAMing
<value> (see page 512)
:SBUS<n>:SPI:FRAMing?
(see page 512)
<value> ::= {CHIPselect |
{NCHipselect | NOTC} | TIMeout}
:SBUS<n>:SPI:SOURce:C
LOCk <source> (see
page 513)
:SBUS<n>:SPI:SOURce:C
LOCk? (see page 513)
<value> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:SPI:SOURce:F
RAMe <source> (see
page 514)
:SBUS<n>:SPI:SOURce:F
RAMe? (see page 514)
<value> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:SPI:SOURce:M
ISO <source> (see
page 515)
:SBUS<n>:SPI:SOURce:M
ISO? (see page 515)
<value> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:SPI:SOURce:M
OSI <source> (see
page 516)
:SBUS<n>:SPI:SOURce:M
OSI? (see page 516)
<value> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA
<string> (see
page 517)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA?
(see page 517)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
