Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-13
YC5
36 DLP_CLR_CLK - - Not used
Connected to
feed PWB 1
37 DLP_CLR_RDY - - Not used
38 DLP_CLR_DIR - - Not used
39 GND - - Ground
40 REG_MOT_PD O 0/3.3 V DC RM control signal
41 REG_MOT_CLK O 0/3.3 V DC (pulse) RM clock signal
42 REG_MOT_REM(
CL)
O 0/3.3 V DC RM/RCL: On/Off
43 GND - - Ground
44 IH_FAN_L O 0/24 V DC IHFM: On/Off
45 IH_FAN_H O 0/24 V DC IHFM: On/Off
46 IH_PWB_FAN_AL
M
I 0/3.3 V DC IHFM alarm signal
47 POWER_OFF O 0/3.3 V DC Power off signal
48 DRM_HEAT - - Not used
49 IH_PWB_FAN_AL
M(U)
- - Not used
50 GND - - Ground
YC6
1 GND - - Ground
Connected to
feed PWB 1
2
MAIL_SDI
I 0/3.3 V DC (pulse) MAIL serial communication data sig-
nal
3
NC
- - Not used
4
MAIL_CLK
O 0/3.3 V DC (pulse) MAIL clock signal
5
MAIL_SDO
O 0/3.3 V DC (pulse) MAIL serial communication data sig-
nal
6
MAIL_RDY
I 0/3.3 V DC MAIL ready signal
7
MAIL_SEL
O 0/24 V DC MAIL select signal
8
GND
- - Ground
9
MAIN_HEAT
- - Not used
10
SUB_HEAT
- - Not used
11 ZEROC - - Not used
12 FSR_RELAY O 0/3.3 V DC Fuser relay signal
13 PRESS_REM - - Not used
14 EXIT_REAR_FAN
_L
O 0/24 V DC ERFM: On/Off
15 EXIT_REAR_FAN
_H
O 0/24 V DC ERFM: On/Off
16 GND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
