Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-14
YC6
17 FSR_CL_REM - - Not used
Connected to
feed PWB 1
18 FSR_MOT_REM O 0/3.3 V DC FUM: On/Off
19 FSR_MOT_CLK 0/3.3 V DC (pulse) FUM clock signal
20 FSR_MOT_RDY O 0/3.3 V DC FUM ready signal
21 FSR_MOT_DIR O 0/3.3 V DC FUM drive switch signal
22 FSR_MOT_BRK O 0/3.3 V DC FUM break signal
23 GND - - Ground
24 MPF_TABLE I 0/3.3 V DC MPTSW: On/Off
25 MPF_WID1 I 0/3.3 V DC MPPWSW: On/Off
26 MPF_WID2 I 0/3.3 V DC MPPWSW: On/Off
27 MPF_WID3 I 0/3.3 V DC MPPWSW: On/Off
28 MPF_LNG I 0/3.3 V DC MPPLSW: On/Off
29 GND - - Ground
30 MPF_PPR I 0/3.3 V DC MPPS: On/Off
31 MPF_UP I 0/3.3 V DC MPLS1: On/Off
32 MPF_DOWN I 0/3.3 V DC MPLS2: On/Off
33 MPF_JAM I 0/3.3 V DC MPFS: On/Off
34 MPF_CL O 0/24 V DC MPPFCL: On/Off
35 MPF_LIF2 O 0/24 V DC MPLM: On/Off
36 MPF_LIFT1 O 0/24 V DC MPLM: On/Off
37 GND - - Ground
38 TC_MOT_LOCK - - Not used
39 TC_TONER_LED - - Not used
40 TONER_FULL - - Not used
41 TC_TONER_VCO
NT
- - Not used
42 INTER_LOCK - - Not used
43 DU2_MOT_PD O 0/3.3 V DC DUM2 control signal
44 DU2_MOT_CLK O 0/3.3 V DC (pulse) DUM2 clock signal
45 DU2_MOT_REM O 0/3.3 V DC DUM2/DUCL2: On/Off
46 GND - - Ground
47 DU_OPEN I 0/3.3 V DC DUCSW: On/Off
48 DU_FAN - - Not used
49 PRESS_MOT_RE
M1
O 0/24 V DC TRRM: On/Off
50 PRESS_MOT_RE
M2
O 0/24 V DC TRRM: On/Off
51 PRESS_RLS_SE
NS
I 0/3.3 V DC TRRS: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
