Group 7 Data/Programming Page 119
Release R1.03e LEIBINGER JET3
7.5.4 Login
With the option <Login> an user can login during the operation to e.g. carry out
functions which are still not enabled for the original logged in user.
Further more the logged in user can logout also during the operation and can
therefore prevent a change of the settings by unauthorized staff.
7.5.4.1 Layout and call login-/logout dialog
Figure 64
Login (Call dialog)
1 – Button <Extra> 6 – Input field <Password>
2 – Option <Login> 7 – Button <Login>
3 – Direct button (Icon) 8 – Button <Logout>
4 – Dialog field <Current login> 9 – Button <Cancel>
5 – Title bar with user display
1
2
3
o
r
4
7
8
9
5
6
5
o
r
4
9
Dialog (with already logged user)
Dialog (no user
logged)
