7.5.5.6 Save graphic/Save graphic as
With the option <Save> an open graphic is saved under the current name. The
existing data will be overwritten.
With the option <Save as> you can save the current opened or new created
graphic under a new name.
Attention! If the graphic is saved with the option <Save> or under
an existing filename, no safety query is generated. The existing data
will be overwritten.
Figure 73
Graphic editor (Save graphic)
1 – Button <File> 6 – Display <Filename>
2 – Option <Save as> 7 – Keyboard field
3 – Window <Save graphic> 8 – Button <Enter>
4 – Selection field <Graphic list> 9 – Button <Save>
5 – Pop-up window<Search in> 10 – Button <Cancel>
1
2
5
1
0
6
7
9
4
8
3
