8.4.3 Position settings
With the position inputs you can position the printing
object accurately (pixel
accurate).
Note:
Important for the displayed position is not the printing element but the
position of the displayed object frame.
Figure 98
1 – Display field <X – Position>
2 – Display field <Y – Position>
Set object position
8.4.4 Bold level (Bold text)
To write a printing text “bold” you have to determine a bold level. The level can be
between 0 – 7.
To get a bold text several dots are placed parallel (multiplication of strokes).
Example
0 = no bold text (single strokes)
1 = 2 dots are placed parallel (2 strokes)
2 = 3 dots are placed parallel (3 strokes)
…..
7 = 8 dots are placed parallel (8 strokes)
The set value is shown on the accordant display field.
Figure 99
Bold text
2
1
Darstellung:
normal Fettdruck
