Leibinger JET3 - Close Job Editor

Group 8 Job editor Page 162
Release R1.03e LEIBINGER JET3
8.3.3 Close job editor
Figure 94
Close job editor
1 – Button <Job> 4 – Button <Cancel>
2 – Option <Close Editor> 5 – Button <No>
3 – Safety query 6 – Button <Yes>
With the option <Close Editor> you can close the job editor.
If changes have been carried out at the opened job, an accordant safety query (3) is
faded in.
In this case the following possibilities are available:
 Press the button <Cancel>
(4) to abort the process and to go back to the
editor.
 Press the button <No> (5) to leave the editor without saving the job.
 Press the button <Yes> (6) to save the job when leaving the editor. Attention!
The saving happens under the current data file name. The existing data will be
overwritten!
1
2
4
6
3
5
