Leibinger JET3 - Number Blocks

Group 6 Operation – Elements and procedures Page 52
Release R1.03e LEIBINGER JET3
6.3.1 Number blocks
Figure 16
1 – Display
2 – Button <Backspace>
3 – Button <del>
4 – Button <Z>
5 – Button <Y>
6 – Button <Return>
Structure of the number blocks
The figures are entered with the number blocks.
The entered value is shown in the Display (1).
The button < Backspace ←> (2) deletes the character in front of (to the left of) the
current cursor position.
The button <del> (3) enables the deletion of the characters behind (to the right of)
the current cursor position.
With the button <Z> (4) you can shift the current
cursor position by one digit to
the right.
With the button <Y> (5) you can shift the current cursor position by one digit to
the left.
With the button <Return ↵> (6) you can take over the input and the number block
closes.
2
3
6
1
4
5
3
6
