8.5.1.5 PrintGo-source (Print start query)
To inform the JET3 when a printing text should be printed, a so called Print-Go
signal is required. It can be generated internally, depending on the set printing
parameters, as well as externally by a sensor (e.g. light barrier, product sensor etc.).
This sensor is called as Print-Go source.
Extern: If this function is activated an external sensor has to be connected to the
interface X5 of the LEIBINGER JET3.
Pos. edge:
Neg. edge:
Note:
The product sensor 24V can be NPN- or PNP-connected.
Internal: If this function is activated a print is generated depending on the set
printing parameters.
Note:
A connected sensor is not inquired.
Figure 107
PrintGo-source (Print start query)
