Leibinger JET3 - Carry out Settings of Job Editor

Group 8 Job editor Page 185
Release R1.03e LEIBINGER JET3
8.6 Carry out settings of job editor
With the display tools you can change the settings of the job editor. The following
functions are available:
 Enlarge and reduce display size (Zoom in/out)
 Show grid
 Catch active
 Editor Settings
1. Editor settings
With the option <Editor Settings>
you can set the editor size (width and height
of the display area) as well as the grid size.
Proceeding:
 Press the button <View> (1) and the option <Editor Settings> (2).
 The window <Editor Settings> (3) is faded in.
 With the Arrow buttons (4) you can increase or reduce the values of the
editor size and the grid size by one step.
alternatively
 Click in the appropriate display field (5) of the value which you would like to
change. A number block opens for input Now enter the requested value.
Note:
The editor height is specified and cannot be changed.
You will find further information regarding the working with
number blocks in the chapter Number block!
 The button <OK> (6) closes the window.
You will find further information regarding the further display
tools in the chapter Display tools!
