Group 7 Data/Programming Page 125
Release R1.03e LEIBINGER JET3
7.5.5.2 Organization tools
With the button <Data file> you can select the organization tools of the editor.
Figure 69
Graphic editor (Organization tools)
1 – Button <File> 4 – Organization tool <Save>
2 – Organization tool <New> 5 – Organization tool <Save as>
3 – Organization tool <Open> 6 – Organization tool <Close>
Pos. Org.-tool Function
2. New Provides the creation of a new graphic. An empty input
field is created.
3. Open Provides opening of an existing graphic.
4. Save Saves the current loaded graphic under the existing
name.
5. Save as Saves the current loaded or new created graphic under a
new name.
6. Close Closes the graphic editor. If carried out inputs or graphic
changes have been not saved yet, an accordant safety
query is faded in.
