Group 8 Job editor Page 175
Release R1.03e LEIBINGER JET3
8.5.1.7 Monitoring functions
Two monitoring functions are available. Monitoring functions are especially required
for high printing speeds.
Figure 109
Monitoring functions
PrintGo-monitoring: If the function is activated it is monitored if every Print-Go
signal can be processed. If a signal can be not processed, a
certain error message is generated.
Example:
A Print Go is generated and is printed. The next
PrintGo is generated; if the printing process is not finished yet,
an error message is generated on the display.
StrokeGo-monitoring: If the function is activated, the stroke output is monitored,
that means if the StrokeGo-signal is generated faster than the
printer can output the several strokes, an error message is
also generated.
Example:
If the production speed with the set parameters is
too high, stroke errors can be caused. The following error
message appears on the display:
