Group 8 Job editor Page 180
Release R1.03e LEIBINGER JET3
8.5.3.2 Font width (Stroke distance)
The setting determines the print width. The print width is determined by the
horizontal drop distance of the strokes. The input happens in the measurement
which has been selected in the basic settings.
The set value is shown on the accordant display field.
As higher the entered value, as larger the distance between the several strokes.
Figure 113
Font width
8.5.3.3 Orientation
With the Pop-up window <Orientation>
(1) you can rotate all printing elements by
180°.
To get a reflection you have to activate the control <mirrored> (2).
Attention! The made settings have not only an effect on single
printing objects but on the complete print-band!
Figure 114
Orientation
1 – Pop-up window <Orientation> 2 –Control box <mirrored>
2
1
normal dis
p
la
y
mirrored
180° rotated
180° + mirrored
