Group 7 Data/Programming Page 131
Release R1.03e LEIBINGER JET3
Proceeding:
 Press the button <File> (1) and the option <Save as> (2).
 The window <Save Graphic> (3) is faded in.
 The names of the already existing graphics are displayed in the selection field
<Graphic list> (4). With the Pop-up window <Search in> (5) you can select
the different memory locations.
 Click in the display <Filename> (6). A keyboard field (7) opens for input.
You will find further information regarding the working with
keyboard fields in the chapter Keyboard fields!
 Enter the requested name.
 Press the button <Enter> (8) of the keyboard field. The entered name will be
taken over to the display <Filename> (6).
 Press the button <Save> (9) to finish the memory process or press the button
<Cancel> (10) to cancel the process.
