Group 7 Data/Programming Page 145
Release R1.03e LEIBINGER JET3
Attention! To avoid faulty operation you have to carry out the
calibration carefully!
Proceeding:
Press the button <Extra> (1) and the option <Touch Calibration> (2).
The calibration window (3) opens.
Now press carefully on the middle of the calibration point 4). Repeat the process
as long as the calibration point moves on the display.
If the settings are calculated an accordring message 5) is displayed on the upper
area of the calibration window. Now press any point on the Touch Display to
accept the settings.
The message <Touch calibration successfully> (6) is faded in.
Finally press the button <OK> (7) to finish the process.
