Group 5 Transport/Start up Page 31
Release R1.03e LEIBINGER JET3
Figure 6
Grounding scematic and gounding point
1 – Printer cabinet 4 – Grounding line 7 – Grounding symbol-label
2 – Installation (machine) 5 – Umbilical
3 – Print head 6 – Grounding point (M6)
5
6
7
Grounding scematic
ground / earth
4
1
3
2
