Group 5 Transport/Start up Page 33
Release R1.03e LEIBINGER JET3
Figure 7
Print head installation (Example)
1 – Product 4 – Sensor 6 – Umbilical (Hose connection)
2 – Conveyor belt 5 – Print head 7 – Print head adapter
3 – Encoder (accessories)
3
5
4
2
1
= Conveying direction
6
7
