Group 5 Transport/Start up Page 38
Release R1.03e LEIBINGER JET3
Basic data /Recommended working conditions:
Signal Parameter Value
Input level High 15 up to 30V
Input level Low -3,5V up to 3,5V (or high
resistance)
All signals
Input resistance 6,8kOhm
Increment Counter/
Reset Counter
Minimum pulse width 250µs
Power ON Minium pulse width 2,5 s
Jobselect 0-9 Maximum duration
of bounce
10 ms
(2)
Input 0-5 Minimum pulse widths Depending on assigned function
(see following table)
In the following table you will find the minimum pulse widths which are required to
release the assigned function at the X4 plug.
Function Minium pulse width
Open nozzle 300ms
Close nozzle 300ms
Print start 500ms
Print stop 500ms
Turn off printer 750ms
Mirrored horizontally 200ms
Gauger synchronization signal 200ms
The function allocations of the inputs 0 up to 5 happens by the
software of the JET3 in the menu Settings X I/O-Settings X Inputs.
You will find a circuit diagram of the interface in the appendix of this
manual!
(1)
All 24V inputs which are designated with (1) are protected by a self-reset fuse with 700 mA.
(2)
For a change of the Jobselect inputs it has to be carried out within the duration of bounce,
that means only after termination of this period of time the new Jobselect No. is validated.
