Group 6 Operation – Elements and procedures Page 58
Release R1.03e LEIBINGER JET3
Figure 20
Switch-on procedure with password protection
1 – TFT-Touch-Display 6 – Dialog field <Current login>
2 – Message <Initialization> 7 – Input field <Password>
3 – Main menu 8 – Keyboard field
4 – Message <Bleeding> 9 – Button <Enter>
5 – Button <Cancel> 10 – Button <Login>
1
5
3
2
4
6
8
9
10
7
