Leibinger JET3 - Page 76

Group 7 Data/Programming Page 76
Release R1.03e LEIBINGER JET3
Proceeding:
 Press on the register card <Language/Unit> (2) to select the functional area.
 Press on the arrow button of the accordant pop-up window. The pop-up
window opens for selection.
 Now select the requested language or the requested keyboard font.
3. Measuring unit:
The two different measuring units „mm“ and „inch“ are available.
Figure 35
Set measuring unit
1 – Menu <Basic Settings> 3 – Pop-up window <Measuring unit>
2 – Register card <Language/Unit>
Proceeding:
 Press on the register card <Language/Unit> (2) to select the functional area.
 Press on the arrow button of the pop-up window <Measuring unit> (3). The
pop-up window opens for selection.
 Now select the requested measuring unit.
2
1
3
