Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1033
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00983
C00985
C00986
C00987
C00988
Parameter | Name:
C00983 | Delay
Data type: UNSIGNED_16
Index: 23592
d
= 5C28
h
Setting range (min. value | unit | max. value)
0 ms 4000
Subcodes Lenze setting Info
C00983/1 50 ms Delay Imax
C00983/2 1000 ms VFC
: Voltage ramp after overvoltage oU
• From version 15.00.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00985 | SLVC: Gain of field current controller
Data type: INTEGER_16
Index: 23590
d
= 5C26
h
Gain of the direct-axis current difference (Id) between setpoint and actual current for the voltage model of the
sensorless vector control (SLVC
)
• The gain should be selected within the range 0 ...1 %.
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 20.00 0.50 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00986 | SLVC: Gain of cross current controller
Data type: INTEGER_16
Index: 23589
d
= 5C25
h
Gain of the IQ difference for the voltage model of the sensorless vector control (SLVC)
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 20.00 0.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00987 | Inverter motor brake: nAdd
Data type: INTEGER_16
Index: 23588
d
= 5C24
h
From version 04.00.00
Speed lift which is connected in pulses to the brake ramp when the motor is braked.
Inverter motor brake
Setting range (min. value | unit | max. value) Lenze setting
0 rpm 1000 power-related (see table
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00988 | Inverter motor brake: PT1 filter time
Data type: INTEGER_16
Index: 23587
d
= 5C23
h
From version 04.00.00
PT1 filter time for smoothing the speed lift which is added in pulses (C00987
)
Inverter motor brake
Setting range (min. value | unit | max. value) Lenze setting
0.0 ms 100.0 0.0 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
