17 Function library
17.1 Function blocks | L_Curve_3
1339
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameters
Designator
Data type
Value/meaning
nOut_a
INT
Output value (y)
• ±16384 ≡ ±100 %
• Internal limitation to ±32767 (±199.99 %)
When using the FB for tensile force characteristic (from V12.00.00):
Current tensile force setpoint in [%]
• 16384 ≡ 100 %
bLimit
BOOL
"Limitation active" status signal
TRUE The output value is limited to ±199.99 %.
nCurveValue_a
INT
From version 12.00.00
Current characteristic value of the tensile force characteristic in [%]
Parameters Possible settings Info
C00959/3
-199.99 % 199.99 Output value
•Read only
C01030/1
Function selection
0 Out = 0 FB deactivated (Lenze setting)
1Out = In
2Out = f(In) In preparation!
3 Out = f(table) See description of L_Curve_1:
Function 3: nOut_a = f(table)
4 Out = f(characteristic) Use of the L_Curve_3 for tensile
force characteristic
C01031/1 -199.99 % 199.99 Upper limit for input value
• Lenze setting: 199.99 %
C01031/2
-199.99 % 199.99 Lower limit for input value
• Lenze setting: -199.99 %
C01033/1...32
-32767 32767 X values for characteristic function
• Subcodes 1 ... 32 correspond to
interpolation point values
X1 ... X32.
• ±16384 ≡ ±100 %
•Lenze setting: 0
See description of L_Curve_1:
Function 3: nOut_a = f(table)
C01034/1...32 -32767 32767 Y values for characteristic function
• Subcodes 1 ... 32 correspond to
interpolation point values
Y1 ... Y32.
• ±16384 ≡ ±100 %
•Lenze setting: 0
See description of L_Curve_1:
Function 3: nOut_a = f(table)
