6 I/O terminals
6.1 Digital input terminals
338
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Counting input DI6 Using DI1(6) as counting input
bCountIn1_Compare
BOOL
Status signal "Comparison value reached"
FALSE Current count value < comparison value (C02840/4
)
TRUE Current count value ≥ comparison value (C02840/4
)
wCountIn6_HW
wCountIn6_LW
C02841/2 | WORD
Current count value
• Output as High and Low word (without sign)
• Possible counting range: 0 ... 2
31
-1
Frequency input DI6/DI7 Using DI1(6) and DI2(7) as frequency inputs
nFreqIn67_a
C00446/2 | INT
Output frequency as scaled analog signal in [%]
nFreqIn67_v
C00445/2 | INT
Output frequency as speed signal in [inc/ms]
High current output Switching status of the motor holding brake at the high current output
bOutHC_BrakeApplied
BOOL
(from version 15.00.00)
Switching status of a motor holding brake connected to the high current output
• The inverted signal logic of this status signal corresponds to the evaluation of a
real brake contact which provides the FALSE state in case of a released holding
brake and the TRUE state in case of a closed holding brake.
FALSE High current output is controlled if an external 24-V supply is
available (holding brake is released).
TRUE High current output is not controlled (holding brake is closed) or
external 24-V supply is not available.
Designator
DIS code | data type
Value/meaning
