11 System bus "CAN on board"
11.8 Process data transfer
732
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
The communication parameters such as the transmission mode and cycle time can be set freely for
every PDO and independently of the settings of other PDOs:
Blocking time
In C00324/x
a "blocking time" can be set which defines the shortest transmission cycle with the
transmission type"asynchronous - manufacturer-specific/device profile-specific".
Example: Cycle time = 500 ms, blocking time = 100 ms, sporadic data change:
• With a sporadic data change < 500 ms, quickest transmission takes place every 100 ms due to
the set blocking time (event-controlled transmission). The transmission cycle timer is reset to 0
if the transmission has been activated in an event-controlled way.
• In the case of a sporadic data change > 500 ms, due to the cycle time set, transmission takes
place every 500 ms (cyclic transmission).
 Tip!
The communication parameters can also be set via the following CANopen objects:
• I-1400
... I-1403: Communication parameters for RPDO1 ... RPDO4
• I-1800
... I-1803: Communication parameters for TPDO1 ... TPDO4
Parameters Info Lenze setting
Value Unit
CAN1_OUT
C00322/1
Transmission mode 254
C00324/2
Blocking time 0 ms
C00356/5
Cycle time 0 ms
C00358/1
Data length 8 Bytes
CAN2_OUT
C00322/2
Transmission mode 254
C00324/3
Blocking time 0 ms
C00356/2
Cycle time 0 ms
C00358/2
Data length 8 Bytes
CAN3_OUT
C00322/3
Transmission mode 254
C00324/4
Blocking time 0 ms
C00356/3
Cycle time 0 ms
C00358/3
Data length 8 Bytes
CAN4_OUT (from version 15.00.00
C00322/4
Transmission mode 254
C00324/5
Blocking time 0 ms
C00356/6
Cycle time 0 ms
C00358/4
Data length 8 Bytes
CAN1_IN ... CAN4_IN
C00323/1...4
Transmission mode CAN1_IN ... CAN4_IN
• In the case of the RPDO serves as
monitoring setting in the case of sync-
controlled PDOs.
254
