11 System bus "CAN on board"
11.11 CANopen objects implemented | I-1016
760
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
I-1016
Monitoring time for the nodes to be monitored via heartbeat. Heartbeat protocol ( 749)
• The parameterised time is rounded down to an integer multiple of 5 ms and must have a greater
value than the heartbeat producer time of the node to be monitored.
[11-4] Data telegram assignment
Index:
I-1016
Name:
Consumer heartbeat time
Subindex Default setting Setting range (min. value | unit | max. value) Access Data type
0: Highest subindex supported BaseLine C: 1
StateLine C: 7
HighLine C: 15
TopLine C: 15
- (read access only) ro U16
1 ... n: Consumer heartbeat time 0 0 65535 rw U16
Subindex Meaning Lenze code
0 Number of nodes to be monitored
1 ... n Node ID and heartbeat time of the node to be monitored Node ID:
C00385/x
Heartbeat time:
C00386/x
8th byte 7th byte 6. byte 5th byte
Data 4 Data 3 Data 2 Data 1
Bit 31 ... bit 24 Bit 23 ... Bit 16 Bit 15 ... Bit 0
0
(Reserved)
Node ID Heartbeat time
in [ms]
