Lexmark CS310 User Manual

Bin‑full/narrow media sensor service check
Actions Yes No
Step 1
Open the front cover, and inspect the bin-full/narrow media sensor (A)
located towards the front of the top cover assembly.
Is the bin‑full/narrow media sensor dislodged or damaged?
Repair or replace the
bin-full/narrow media
sensor. See
“Bin‑full/
narrow media sensor
removal” on page
297.
Go to step 2.
Step 2
Does the flag rotate freely?
Go to step 3. Reposition or replace
the flag. See
“Bin‑full/
narrow media sensor
removal” on page
297.
5027
Diagnostic information
115

Lexmark CS310 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 60, 000 pages
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Standard Output Capacity	125 sheets
Recommended Monthly Page Volume	500 - 3, 000 pages
Operating Systems Supported	Windows, Linux
