Lexmark CS310 User Manual

Parts catalog
• “Legend” on page 316
• “Assembly 1: Covers” on page 317
• “Assembly 2: Frames” on page 321
• “Assembly 3: Electronics” on page 323
• “Assembly 4: Cables and sensors” on page 327
• “Assembly 5: Media drawers and trays” on page 329
• “Assembly 6: Options and miscellaneous” on page 331
Legend
The following column headings are used in the parts catalog:
• Asm‑index—Identifies the assembly and the item in the diagram. For example, 3‑1 indicates Assembly 3 and item
1 in the table.
• Part number—Identifies the unique number that correlates with the part.
• Units/mach—Refers to the number of units actually used in the base machine or product.
• Units/option—Refers to the number of units in a particular option.
• Description—A brief description of the part.
The following abbreviations are used in the parts catalog:
• NS (not shown) in the Asm‑index column indicates that the part is procurable but is not pictured in the illustration.
• PP (parts packet) in the Description column indicates that the part is contained in a parts packet.
5027
Parts catalog
316

Lexmark CS310 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 60, 000 pages
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Standard Output Capacity	125 sheets
Recommended Monthly Page Volume	500 - 3, 000 pages
Operating Systems Supported	Windows, Linux
