Fuser service check
Actions Yes No
Step 1
Some of these errors are caused by a faulty component on the LVPS. Check
the history file in the printer to verify other occurrences. If there are
others, then replace the LVPS. See
“Low‑voltage power supply (LVPS)
assembly removal” on page 226.
Does this solve the problem?
The problem is solved. Go to step 2.
Step 2
Turn the printer off, and remove the rear cover. See
“Rear cover removal”
on page 290.
Check the cable at JFUSES1 for proper connection to the controller board,
the cable for pinch points, and the cable or connector for any other
damage.
Is the cable damaged?
Replace the fuser
cable.
Go to step 3.
5027
Diagnostic information
86
