3 Turn on the printer.
4 Release the buttons when the installed memory and processor speed displays.
5 Select Exit Diags to exit Diagnostics mode.
For CS410 and CS510 models:
1 Turn off the printer.
2 Press and hold 3 and 6.
3 Turn on the printer.
4 Release the buttons when the installed memory and processor speed displays.
5 Select Exit Diags to exit Diagnostics mode and return to the printer home screen.
REGISTRATION
Print registration makes sure the black printing plane is properly aligned on the page. This is one of the steps in aligning
a new printhead. It is also the first step in aligning the duplex registration. See
“Quick Test” on page 168.
To set Registration:
1 Select Registration from the Diag Menu, and press Select.
2 Use Left or Right to select Print Quick Test, and press Select.
See
“Quick Test” on page 168 for addition information.
The message Printing... appears on the display, and the page prints.
Retain this page to determine the changes you need to make to the margin settings.
3 Press Select to enter the Registration.
4 Use Left or Right to select the margin setting you need to change, and press Select.
5 Use Left to decrease or Right to increase the offset values, and press Select to confirm the value. The message
Submitting changes displays, and the original margin setting screen appears.
The print registration ranges are:
Description Value Direction of change
Top margin -50 to +50
Each increment corresponds to 8 scans at a 600
dpi scan rate (0.0133 inches or 0.339 mm).
The default is 0.
A positive change moves the image down the
page and increases the top margin. A negative
change moves the image up and decreases the
top margin. No compression or expansion occurs.
Bottom margin -25 to +25
Each increment causes approximately 0.55 mm
shift in the bottom margin.
The default is 0.
A positive offset moves text down the page and
narrows the bottom margin, while a negative
offset moves text up the page and narrows the
bottom margin. The image is compressed or
expanded.
Left margin -25 to +25
Each increment corresponds to 4 pixels at 600 dpi
(0.00666 in. or 0.1693 mm).
The default is 0.
A positive change moves the image to the left,
and a negative change moves the image to the
right.
5027
Service menus
167

Lexmark CS310 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 60, 000 pages
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Standard Output Capacity	125 sheets
Recommended Monthly Page Volume	500 - 3, 000 pages
Operating Systems Supported	Windows, Linux
