Lexmark CS310 User Manual

The symptoms described in this chapter might require replacement of one or more CRUs (Customer Replaceable Units)
designated as supplies or maintenance items, which are the responsibility of the customer. With the customer's
permission, you might need to install a developer (toner) cartridge.
Initial print quality check
Before troubleshooting specific print problems, complete the following initial print quality check:
1 Print a menu settings page, and then check the life status of all supplies. Any supplies that are low should be replaced.
Be sure to keep the original menu page to restore the customer's custom settings if needed.
2 On the menu page, make sure the following settings are at the default level:
• Color Correction: Set to Auto.
• Print Resolution: Set to 4800 dpi (print quality problems should be checked at different resolution settings).
• Toner Darkness: Set to 4 (default).
• Color Saver: Set to OFF.
• RGB Brightness, RGB Contrast, RGB Saturation: Set to 0.
• Color Balance: Select Reset Defaults to zero out all colors.
• Check the paper type, texture and weight settings against the paper that is loaded in the printer.
3 Inspect the image transfer unit for damage. Replace, if damaged.
4 Inspect the print cartridges for damage. Replace, if damaged.
5 If paper other than 20 lb plain letter/A4 paper is being used, load 20 lb plain letter/A4 and print the Print Quality
pages to see if the problem remains. Use Tray 1 to test print quality problems.
6 Print the Print Quality Pages (Settings>Help>Print Defects Guide/Color Quality), and then look for variations in the
print from what is expected.
7 Check to ensure the correct printer driver for the installed software is being used. An incorrect printer driver for
the installed software can cause problems. Incorrect characters could print, and the copy may not fit the page
correctly.
8 Measure all voltages from the connector to the printer ground.
Toner smear check
Leading edge
Trailing edge
ABC
DEF
5027
Diagnostic information
36

Lexmark CS310 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 60, 000 pages
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Standard Output Capacity	125 sheets
Recommended Monthly Page Volume	500 - 3, 000 pages
Operating Systems Supported	Windows, Linux
