Importing eSF solutions and settings file
After replacing the controller board, import back to the printer the eSF solutions and settings that were exported.
1 POR the printer into Invalid engine mode. See “Entering invalid engine mode” on page 194.
2 Open a Web browser, and then type the printer IP address.
3 Navigate to Settings > Solutions > Embedded Solutions.
4 From the Embedded Solutions page, select the applications you want to import.
5 Click Import.
Ribbon cable connectors
Zero Insertion Force (ZIF) connectors
Zero Insertion Force (ZIF) connectors are used on the boards and cards used in this printer. Before inserting or removing
a cable from these connectors, read this entire section. Great care must be taken to avoid damaging the connector or
cable when inserting or removing the cable.
Warning—Potential Damage: Do not insert the cable so that the contacts are facing the locking actuator. The
contacts always face away from the actuator.
Warning—Potential Damage: Do not insert the cable diagonally into the ZIF socket. This can cause damage to the
contacts on the cable.
Warning—Potential Damage: Avoid using a fingernail, or sharp object to open the locking mechanism. This could
damage the cable.
Warning—Potential Damage: Avoid pressing against the cable when opening the locking mechanism. This can also
damage the cable.
These are the types of ZIF connectors used in this printer:
• Horizontal top contact connector
• Horizontal bottom contact connector
• Vertical mount contact connector
• Horizontal sliding connector
5027
Repair information
205
