Lexmark CS310 - Double Feed and Printout Skewed Service Check

Action Yes No
Step 9
• For 550 input option, replace the optional 550-sheet drawer.
• For 650 input option, replace the optional 650-sheet duo drawer.
Does this fix the problem?
Problem resolved. Go to step 10.
Step 10
a Turn off the printer.
b Remove the rear cover. See
c Disconnect the cable at JOPT1 on the controller board.
d Turn the printer on.
e Measure the voltages below:
JOPT1:
• Pin 2: Ground
• Pin 3: Ground
• Pin 5: +24 V dc
• Pin 6: Ground
• Pin 7: +5 V dc
• Pin 9: Ground
• Pin 10: Ground
Are the voltages correct?
Contact your next level
of support.
Replace the controller
board. See
“Controller
board removal” on
page 291.
Double feed and printout skewed service check
Action Yes No
Step 1
a Fan the media.
b Verify the proper tray settings for the media.
c Check the condition of the multipurpose feeder pick tires.
d Make sure the tray is fully inserted.
e Make sure the paper tray guides are set correctly.
Does the error remain?
Go to step 2. Problem resolved.
Step 2
Is the machine using both 650 and 550 input option tray?
Go to step 3. Go to step 4.
